High density and large capacity
Optical fiber distribution frame configuration requirements
First, the structure of optical fiber distribution frame (20):
1) 7 splice unit boxes (each unit door 430x175mm, each unit box can accommodate 6 splice fiber trays, each splice tray supports 12 core fiber pigtails, the flange is FC/PC);
2) 1 optical splitter unit box (430x175mm);
3) 1 cable fixing unit box (430x355mm);
4) 1 winding unit box (430x290mm);
5) The overall height of the cabinet is 2000mm (increase or decrease in the proportion of height of the splice unit box);
6) The overall width of the cabinet is 900mm;
Second, integrated welding unit box (20)
1) 1 splice unit box (each unit door 430x175mm, each unit box can accommodate 6 splice fiber trays, each splice tray supports 12 core fiber pigtails, the flange is FC/PC);
