Place of Origin:
CHINA
Brand Name:
YUHUI
Certification:
ISO9001
Model Number:
Rain Proof Flexible Size Plastic Patch Panel Patch Cord with white and Black and Other Color
1 - Mic in/MIC (microphone input)
2—GND (ground)
3 - Mic Power/Mic VCC/MIC BIAS (microphone voltage)
4——No pin
5 - LINE OUT FR (Right Channel Pre Audio Output)
6 - LINE OUT RR (right channel rear audio output)
7-NO pin
8——NO pin
9 - LINE OUT FL (left channel front audio output)
10 - LINE OUT RL (do channel rear audio output)
When connecting the front audio, you only need to follow the above definition and connect the corresponding line. In fact, the 5Pin and the 6Pin, the 9Pin, and the 10Pin are connected by a single wire in some cases, and the same effect can be achieved.
It looks like the line is a bit more, but it's also very easy to remember. You may wish to follow the method I remember. First of all, keep in mind the first three. The first is the mic input, the second is grounded, the third is the mic voltage, then the 5pin and 6pin plug in the right channel, and the ninth pin and 10pin plug in the left channel. From the top down, Mic in, Mic voltage, right channel, left channel, plus a ground. Is it so simple?
